Pickup Assembly Jig · WT-PB

Precision Bass® Assembly Jig

$39.95

A precision assembly jig for Precision Bass® split-coil pickup bobbins. Designed to keep the flatwork and pole pieces aligned during assembly for cleaner, faster, and more repeatable builds.

Jig only. Flatwork, pole pieces, magnets, wire, and other pickup components shown in demonstration photos are sold separately.

Price is shown in your selected store currency. Canadian taxes are calculated at checkout where applicable.

Split-coil Precision Bass® format Built for Precision Bass® bobbin assembly

Eyelet clearance Room for installed bottom-flatwork eyelets

Bench-ready workflow Assemble, remove, and wind

Built for pickup makers

Keep each split-coil bobbin aligned during assembly.

The WT-PB holds the flatwork securely while the pole pieces are installed, helping keep the geometry consistent from one bobbin to the next.

Flatwork compatibility

Pole piece diameter 0.187 in / 4.75 mm

Winding cavity 0.34 in / 8.7 mm

Top flatwork 0.093 in / 2.36 mm

E-to-G center spread 1.12 in / 28.5 mm

Bottom flatwork 0.093 in / 2.36 mm

Total stack 0.62 in / 14.73 mm

What you get

Simple, purpose-built tooling.

1 × WT-PB Assembly Jig

The Precision Bass® assembly fixture shown on this page.

Matching flatwork sold separately

Choose the corresponding Precision Bass® flatwork set independently from the jig.

Components not included

Pole pieces, magnets, eyelets, wire, flatwork, and other pickup parts are not included.

Geometry

Precision Bass® split-coil format.

Designed around the familiar split-coil Precision Bass® pickup layout, with each bobbin handling two string positions and four pole pieces.

Need matching flatwork?

Pair the jig with the corresponding Winder Tooling Precision Bass® flatwork set.

VIEW FLATWORK
