Telecaster® Bridge Assembly Jig
39.95$
A precision assembly jig for T-style bridge pickup bobbins. Designed to keep flatwork and pole pieces aligned during assembly for cleaner, faster, and more repeatable builds.
Description
WT-TB — Telecaster Bridge Assembly Jig
The WT-TB securely aligns the top and bottom flatwork while the pole pieces
are installed, maintaining consistent spacing and coil geometry while leaving
the pole-piece stagger entirely up to the builder.
Flatwork Compatibility
Pole piece diameter |
0.187 in / 4.75 mm |
Pole pitch |
0.433 in / 11.00 mm |
Low-E to high-E spread |
2.165 in / 54.99 mm |
Top flatwork thickness |
0.062 in / 1.57 mm |
Bottom flatwork thickness |
0.093 in / 2.36 mm |
Coil space (inside-to-inside) |
0.469 in / 11.90 mm |
Designed around T-style bridge pickup geometry used across
early-’50s blackguard-style builds as well as today.
Jig only.
Flatwork, pole pieces, magnets, and other pickup components shown in
demonstration photos are not included.
