Telecaster® Neck Assembly Jig
39.95$
A precision assembly jig for Telecaster® neck pickups, designed to keep the flatwork and pole pieces properly aligned for fast, consistent, and repeatable bobbin assembly.
Description
WT-TN — Telecaster Neck Assembly Jig
The WT-TN securely aligns the top and bottom flatwork while the pole pieces
are installed, helping maintain consistent spacing and coil geometry from one
build to the next.
Flatwork Compatibility
| Pole piece diameter | 0.187 in / 4.75 mm |
| Low-E to high-E spread | 1.9 in / 49.0 mm |
| Top flatwork thickness | 0.062 in / 1.57 mm |
| Bottom flatwork thickness | 0.093 in / 2.36 mm |
| Coil space (inside-to-inside) | 0.469 in / 11.9 mm |
| Total stack | 0.58 in / 15.83 mm |
Designed around traditional T-style neck pickup geometry for consistent
flatwork and pole-piece alignment at the assembly bench.
Jig only.
Flatwork, pole pieces, magnets, cover, wire, and other pickup components shown in
demonstration photos are not included.
Flatwork, pole pieces, magnets, cover, wire, and other pickup components shown in
demonstration photos are not included.
